Chemical Resistant Conveyor Belt
Details
Chemical Resistant Conveyor Belt
Characteristics:
· The rubber cover, which is made from chemical resistant materials, has fine anti-chemical corrosiveness and good physical property.
· It is specially made for those materials which would dissolve expand or corrode the belt.
· Used in transporting chemicals ,pulps,ceramics,fertilizer,or in carting goods with chemicals.
When selecting the chemical-proof Belt Cover Rubber, due to the difference in the type. Density and temperature of the goods to be transported, it is necessary to makie inquiry first.
Technical Data for Reference
| Technical specification HG/T3782-20005 | ||||||||
| Item | Tensile | Elongation | Abrasion | Hardness | Ozone Aging | |||
| MPA≥ | %≥ | mm³≤ | -5+10 | |||||
| Cover rubber | Physics | before aged test | 14.0 | 400 | 250 | 60 | No Crack | |
| After aged test | 12.0 | 340 | - | 65 | - | |||
| Acid resistance | Class | Immerse scald | potency | Temp.X time | Change after Immersed | |||
| Expansion rate | Intensity rate | |||||||
| A1 | （HCI） | 18% | 50℃ X 96h | +10%以下 | -10%以内 | |||
| A2 | （H2SO4） | 50% | 50℃ X 96h | +10%以下 | -10%以内 | |||
| A3 | （NaOH） | 48% | 50℃ X 96h | +10%以下 | -10%以内 | |||
